Basic Pocket Console DMX Dimmer Tester Lighting Portable Console by BCi – Baxter Controls Inc

The Baxter Basic Pocket Console DMX offers a simple, reliable, and cost-effective solution for anyone seeking a compact DMX-512 lighting controller. Built for ease of use, it delivers intuitive, hands-on control in an ultra-compact form factor—perfect for small productions, mobile setups, or as a backup controller for larger lighting systems.

Despite its compact size, this pocket console delivers impressive functionality. It includes eight user-friendly faders (slider pots), each paired with its own bump button for immediate control and triggering. You can patch each fader independently to control up to 512 DMX dimmer addresses, giving you complete flexibility in channel assignment. Assign multiple addresses to a single fader or tailor the patching to match your specific lighting setup.

This lightweight, portable unit fits comfortably in your hand—perfect for technicians, stage managers, or operators who need mobility without sacrificing control. You can power it with a standard 9-volt battery for at least three hours of operation or use the included 120V AC power supply, making it versatile enough for a wide range of venues and applications.

The Baxter Pocket Console outputs standard DMX-512 (1990) protocol at a data speed of 44Hz, ensuring compatibility with a wide range of dimmers, intelligent fixtures, and other DMX-enabled equipment. Optional rugged Pelican cases are available for added protection during transport or storage.

Whether you’re lighting a small venue, running tech rehearsals, or need a portable solution on the go, the Baxter Basic Pocket Console DMX offers simplicity, flexibility, and value in a compact package.

Features

  • Optional Pelican Cases are available
  • Small, lightweight, portable, and designed to be handheld
  • Levels are set using eight faders (slider pots)
  • Each FADER has an associated bump button
  • 512 dimmer addresses are patchable to any of the eight faders
  • The faders are patchable using from 0 to 512 dimmer addresses per fader
  • The unit is powered by a 9v battery OR by a 120v AC power supply

Technical Specifications

  • 9 Volt Alkaline Battery Life – 3 hours minimum
  • 120v AC adapter
  • Number of DMX dimmer addresses supported – 512
  • Number of Faders – 8 with bump buttons
  • Data output – DMX-512 1990 standard
  • Data Speed: 44hz
  • Comes with instructions & 90-day warranty
  • BCI – Baxter Controls, Inc

SKU# Pocket-Console-Basic
